Reverse-engineering motorcycle telemetry

How I reverse-engineered the Yamaha Y-Trac binary format to build an open-source telemetry parser and visualizer, with a lot of help from Claude.

———
Motorcyclist racing on a track

I’m not a motorcyclist. A friend told me he had tried to extract data from his Yamaha Y-Trac telemetry files without success. I said it would be easy with Claude. It became a matter of principle.

The truth is: it took 23% of my weekly Claude Max quota, but I got it done in 48 hours.

What is Y-Trac?

The Yamaha Y-Trac system is a data logger (CCU — Communication Control Unit) installed on some Yamaha motorcycles. It records telemetry at 10 Hz into proprietary .CTRK binary files:

  • GPS: latitude, longitude, speed (from NMEA sentences)
  • CAN bus: engine RPM, gear, throttle position, brake pressure, wheel speed, lean angle, pitch, acceleration, temperature, fuel consumption
  • Electronics: ABS, traction control, slide control, launch control states
  • Lap timing: finish line crossing detection

The official Y-Trac Android app can display this data, but there’s no export functionality. The data is locked in a proprietary format, processed by a native C library (libSensorsRecordIF.so) that ships with the APK.

The reverse-engineering journey

Step 1: Extract the native library

The first step was to get the native library out of the APK. An APK is just a ZIP file:

unzip com.yamaha.jp.dataviewer-v1.3.8.apk -d ytrac_apk

Inside lib/, there are builds for multiple architectures. The x86_64 version is the most useful for disassembly since radare2 has better support for x86 than ARM.

Step 2: Decompile the Java layer with jadx

jadx decompiles Android DEX bytecode back to readable Java. This revealed the JNI interface — the bridge between the Java app and the native C library:

// Key JNI methods from SensorsRecordIF.java
int GetSensorsRecordData(
    String fileName,       // Path to CTRK file
    int fileType,          // 0=CTRK, 1=TRG
    int lapIndex,          // 0-based lap index
    SensorsRecord[] output,// Pre-allocated array
    int maxRecords,        // Max records (72000)
    int[] actualCount,     // Records actually written
    AINInfo ainInfo         // Auxiliary input metadata
);

The SensorsRecord class revealed the complete data structure — 21 telemetry fields, each with its Java type and field name, giving us the expected output format.

Step 3: Disassemble with radare2

radare2 is a reverse-engineering framework. It can disassemble native libraries and let you trace the execution flow. This is where the real detective work happened.

The key function GetSensorsRecordData at address 0xa970 contains the main parsing loop. By tracing its execution, we could identify:

  1. The file structure: a header starting with "HEAD" magic bytes, followed by typed data records, ending with "END."
  2. Record types: type 1 (GPS NMEA), type 3 (CAN bus), type 4 (timestamp), type 5 (lap marker)
  3. 8 CAN message handlers, each decoding specific telemetry channels from 8-byte CAN payloads

For example, CAN ID 0x0209 decodes RPM and gear:

Address 0xe0f2:  RPM = (byte[0] << 8 | byte[1]) / 2.56
Address 0xe131:  Gear = byte[4] & 0x0F
                 if (Gear == 7) Gear = previous_gear  // reject invalid

Each CAN handler was traced to extract the exact byte positions, bit masks, and calibration formulas. In total, 8 CAN IDs decode 21 telemetry channels:

CAN IDChannels
0x0209RPM, Gear
0x0215Throttle (TPS/APS), TCS, SCS, LIF, Launch
0x023EWater temp, Intake temp, Fuel
0x0250Acceleration X, Acceleration Y
0x0258Lean angle, Pitch rate
0x0260Front brake, Rear brake
0x0264Front wheel speed, Rear wheel speed
0x0268Front ABS, Rear ABS

Step 4: Build the Python parser

With all the formulas extracted, I built a Python parser (1031 lines) that reads .CTRK files and outputs calibrated CSV data. The parser:

  1. Validates the "HEAD" magic bytes
  2. Extracts finish line coordinates from the header
  3. Iterates through data records, maintaining CAN channel state
  4. Emits a telemetry record every 100ms (10 Hz)
  5. Detects laps by checking if GPS positions cross the finish line

Step 5: Validate against the native library

This is the part that took the most effort. To validate the parser, I needed reference output from the native library. The problem: the native library only runs on Android.

The solution was to build a Kotlin Android app that:

  1. Loads the native .so via JNI
  2. Calls GetSensorsRecordData for each lap
  3. Exports the results as CSV

Running this through an Android emulator on macOS, I generated reference output for 47 CTRK files.

Then I built a comparison suite that aligns records by GPS position (since timestamps differ slightly between parsers) and compares each of the 22 channels with appropriate tolerances.

Results: 95.4% overall match rate across 301,166 records and 6.6 million individual comparisons. 3 channels achieved a perfect 100% match. The remaining differences are mostly due to architectural choices (continuous vs per-lap processing) rather than formula errors.

graph TB
    subgraph RE["Reverse Engineering"]
        APK["Y-Trac APK"] --> JADX["jadx<br/>(Java decompiler)"]
        APK --> R2["radare2<br/>(disassembler)"]
        JADX --> JNI["JNI interface<br/>Data structures"]
        R2 --> CAN["CAN handlers<br/>Calibration formulas"]
    end

    subgraph VAL["Validation"]
        SO["libSensorsRecordIF.so"] --> ANDROID["Android bridge<br/>(Kotlin + emulator)"]
        ANDROID --> REF["Reference CSV"]
        PY["Python parser"] --> PYCSV["Parser CSV"]
        REF --> CMP["Comparison suite"]
        PYCSV --> CMP
        CMP --> MATCH["95.4% match<br/>301K records"]
    end

    JNI --> PY
    CAN --> PY

The TypeScript rewrite

Once the Python parser was validated, the next step was to make it accessible to everyone — in the browser, no installation required.

The TypeScript version (@tex0l/ctrk-parser) is a zero-dependency, platform-agnostic rewrite that runs in both Node.js and the browser. It achieves 100% match with the Python reference implementation.

On top of the parser, I built an Astro integration (@tex0l/ctrk-astro) with Vue.js components:

  • FileUpload: drag-and-drop with file validation (checks the "HEAD" magic bytes) and Web Worker parsing to keep the UI responsive
  • TrackMap: Leaflet map with color-coded lap polylines
  • TelemetryChart: Chart.js graphs for all 21 channels with LTTB downsampling (5000 points max)
  • LapTimingTable: lap times with delta to best lap and CSV export

The Web Worker approach is key: parsing a large CTRK file (8 MB, ~20,000 records) takes a few seconds. Without the worker, this would freeze the browser tab. With it, the UI stays fully responsive while parsing happens in a background thread.

Try it

You can try it right now on the CTRK Exporter page. Drop a .CTRK file and explore the data — everything runs locally in your browser, no data is sent anywhere.

The source code is available on GitHub. The packages are published on npm:

npm install @tex0l/ctrk-parser   # Parser only
npm install @tex0l/ctrk-astro    # Astro integration
npm install @tex0l/ctrk-cli      # CLI tool

Takeaway

This project was a good test of Claude’s capabilities on a real reverse-engineering task. The AI handled the tedious parts (tracing disassembly, building comparison frameworks, writing boilerplate) while I focused on the interesting decisions (parser architecture, validation strategy, what to optimize).

The one thing that surprised me most: Claude’s ability to read radare2 disassembly output and extract the correct byte positions and calibration formulas. Reverse-engineering is usually a slow, manual process. Having an AI that can process pages of assembly and propose “CAN byte[2] at offset 0xe0f2 is RPM with formula raw / 2.56” is genuinely useful.
